How To Hide Upper Floor Revit

To prevent the floor or slab from being visible in plan view you need to adjust the bottom clip so that it is more than 4 feet above the floor or slab and set the view depth so that it does not include any part of the floor or slab.

How to hide upper floor revit.

There are various ways too hide the hidden lines above the cut line in stairs so as to reduce the clutter in the drawing or may be to show the walls underneath the stairs. Typically the beams should be displayed in architectural drawings. In the main floor level the bottom of the primary range is set to main floor with an offset of 1. If the view range intersects the geometry of a level in your main view that level cannot be used as an underlay in the main view.

Click modify tabview panel hide in view drop down hide elements hide category or hide by filter. Hide an element when you do not want it to appear in a view. If you select hide elements the element is hidden in the view. With hidden lines if they are positioned above the cut plane of the floor plan view with solid contour lines if they are below the cut plane and within the view range of.

When you tried to underlay a floor only doors and windows were visible. Alternatively right click the element and click hide in viewelements category or by filter. When i m looking at the 1st floor i can see all the details of the ground floor making it look too cluttered. In the drawing area select the element to hide.

Hi i m new to revit so sorry for such a noobie question is it possible to hide walls doors etc from the lower floors. This issue occurs because there is an incorrect view range in the main view. You may use a masking region but the best and easiest way in my opinion is to go to visibility graphics then under stairs uncheck above cutmarks and above outlines. Structural beams need to be represented in floor plan views corresponding to the position of the beam compared to the view range settings of the view.

If you select hide.
